    GTC Super Track Tile showing the textured surface over the keel and cushion layers
    Performance Collection

    GTC Super Track Tile

    The leading modular tile track available.

    A four-layer tile built for safer, high-performance play: a soft-touch surface, a rigid diagonal keel for support, and an elastic cushion layer underneath.

    4

    Layer Design

    32

    Cushion Units

    12

    Colors

    Ideal For:

    BasketballPickleballTennisMulti-Sport CourtsSchools & Camps

    Why Choose Super Track?

    Contraction System

    4 elastic arms, elastic pillars, and 8 telescoping spring plates help manage expansion and contraction within 2mm gaps, reducing buckling and cracking from temperature changes.

    Support System

    32 elastic cushion units per tile provide court-grade load-bearing support.

    Textured Surface

    Non-reflective, low-glare finish with an enhanced friction coefficient for anti-slip performance in dry and wet conditions.

    Rounded Corners

    Rounded corner and edge treatment for a cleaner, safer finish.

    Four-Layer Design

    Soft surface, interlock, rigid keel, and elastic cushion work together as one system.

    Dual-Core Elastic Shield

    Soft outer and hard inner cushion cores balance comfort with consistent ball response.

    Four-Layer Structural Design

    Underside of the Super Track Tile showing the diagonal keel and elastic cushion pads
    1. 01

      Surface Layer

      TPE

      Specially modified soft-touch formula with a 3D arrow grain pattern, multi-directional grooves, and micro-foaming for a safe, comfortable feel.

    2. 02

      Interlocking Structural Layer

      TPE

      Connects every tile into one continuous playing surface.

    3. 03

      Keel Layer

      High-Rigidity PP Composite

      45-degree diagonal keel structure delivers rock-solid support underfoot.

    4. 04

      Elastic Cushion Layer

      TPE

      Ultra-soft TPE outer core over a high-strength hard inner core, with wave-pattern 3D friction units and a patented snap design.

    Technical Specifications

    Dimensions12" x 12" x 0.82"
    Weight1.53 lbs per tile
    Coverage1 sq ft per tile
    Surface MaterialModified TPE, micro-foamed
    Keel MaterialHigh-Rigidity PP Composite
    Cushion Units32 per tile
    Expansion GapWithin 2 mm
    Colors12 standard colors

    Specification Sheet

    Download a professional two-page specification sheet with all technical details, color options, and product information.
